Quality Check

Testing gimbal motors and flex ribbons with precision on our test board

Quality Check

Testing gimbal motors and flex ribbons with precision

Gimbal Motors

Each gimbal motor is carefully tested to ensure smooth movement and reliability.

Close-up of a gimbal motor being tested on a specialized test board.
Close-up of a gimbal motor being tested on a specialized test board.
Flex Ribbons

Flex ribbons are connected and tested for durability and proper function.

A flex ribbon cable connected to a test board undergoing quality checks.
A flex ribbon cable connected to a test board undergoing quality checks.

FAQs

What is quality check?

It’s testing gimbal motors and flex ribbons for proper connection.

How do you test gimbal motors?

We connect motors to a test board to verify their function and stability.

Why test flex ribbons separately?

Flex ribbons are delicate; testing ensures they flex correctly and connect well without damage.

What happens if parts fail?

Failed parts are flagged and removed before assembly to avoid issues.

Is testing automated?

Yes, test boards automate checks for accuracy and speed.

How often is quality checking done?

Quality checks happen at multiple stages to ensure every part meets standards.

Gimbal Test

Checking motor precision carefully.

Close-up of a gimbal motor mounted on a test board with wires connected.
Close-up of a gimbal motor mounted on a test board with wires connected.
Flex Ribbon

Testing the flexibility and connectivity of the ribbon cables before assembly to ensure flawless performance.

A technician gently bending a flex ribbon cable connected to a test board under bright workshop lighting.
A technician gently bending a flex ribbon cable connected to a test board under bright workshop lighting.
Final Check

Connecting gimbal motors and flex ribbons to the test board to verify full system integration and quality.

Get in Touch

Questions about our gimbal motor and flex ribbon testing? Reach out anytime.
